FJ1200 Accessible Sidecar

It has an Engineering Report and a Western Australian Department of Transport Motor Vehicle Modification Approval No. 42644, and has passed a Certificate of Inspection MR3327956 from Driver and Vehicle Services on 29/07/2026.

• According to Condition 143, transferring this vehicle requires the following:
  • The purchaser is required to send an email, with the plate number quoted (KA0792), to This email address is being protected from spambots. You need JavaScript enabled to view it.
  • The email will demonstrate evidence of why the purchaser requires a vehicle with those specifications, with details (proof) that it will be used for disability purposes.
  • When Condition 143 has been satisfied, the buyer can complete an MR-9 form to transfer ownership.
• This disability Sidecar Combination has plenty of power and does not slow down on hills (fully laden), being comfortable for the rider, pillion and wheelchair passenger.
• Motorcycle Specifications: Engine.
  • Displacement: 1188cm3 (72.49 cubic inches).
  • Engine: Air-cooled 4 Cylinder In-line 4 Stroke 4 Valves per Cylinder DOHC.
  • Engine Model: 3BC3.
  • Power: 130 HP (94.9 kW) @ 9000 RPM.
  • Power-to-Weight Ratio: 0.37 HP/kg (2.73 kg/HP).
  • Compression: 9.7:1 Bore x Stroke: 77.0 x 63.8mm (3.03 x 2.51 inches).
  • Engine Mounting: Transverse.
  • Spark Plug: NGK, DP8EA-9 or NIPPON DENSO X24EP-U9.
  • Ignition Type: TCI (Transistor Controlled Ignition).
  • Fuel System: Carburettor BS36/MIKUNI.
  • Capacity: 22 Litres Premium Unleaded.
  • Lubrication: Wet Sump.
  • Motor Oil: 20W/40 Type SE Oil Quantity: 4.2 Litres.
• Motorcycle Specifications: Electrics.
  • Electrical: Electric starter, TCI Digital, AC Generator.
  • Battery: YB-14L/12V 14AH.
• Motorcycle Specifications: Transmission.
  • Constant Mesh 5-speed.
  • Clutch: Wet, Multiple Discs, Cable Operated.
  • Final Drive: Chain.
• Motorcycle Specifications: Dimensions/Weights.

  • Length: 2,205 mm.
  • Width: 775 mm.
  • Height: 1,245 mm.
  • Seat Height: 780 mm.
  • Wet (Kerb/Curb) Weight: 261kg (576 pounds).
  • Frame Type: Steel, Twin Spar (Perimeter), Double Cradle.
• Motorcycle Specifications: Suspension/Brakes/Tyres.

  • Front Suspension: Leading Link.
  • Front Brake: Twin Disk (diameter 282 mm).
  • Front Tyre: 120/70 V17-V250.
  • Rear Suspension: Mono Shock, Swingarm.
  • Rear Brake: Single Disk (diameter 282 mm).
  • Rear Tyre: 150/80 V16.
  • Rear Shock Absorber: Gas, Coil Spring, Oil Damper.
  • Minimum Turning Diameter (with Sidecar): 8.2 m.
• Sidecar Specifications Body.

  • Construction: Steel Chassis, Fibreglass Boat, Wooden Floor, Steel Ramp.
• Sidecar Specifications Safety.

  • Occupant Restraint: Lap and Sash Seat belt, APV Safety Products ID3098 Certified to AS/NZS2596.
  • Wheelchair Restraint: 4 Point QStraint Q86209 retractable wheelchair tie-downs. Compatible Anchorage: Slide 'N Click, L-
  • Track and A-Track Floor Anchorages.
  • Wheelchair Type: Will suit scooters, small or large manual and electric wheelchairs.
  • Restraint Compliance: Crash tested to 30mph, 20g's. Meets or exceeds the following standards and regulations: SAE J2249,
  • ISO 10542, FMVSS 209, 302, 210, 222, CMVSS 209, CSA Z605, AS 2596, ADA, ISO 9000 Registered.
• Sidecar Specifications: Dimensions/Weights.

  • Ramp Length Folded: 2100 mm.
  • Ramp Length Extended: 3350 mm.
  • Width: 1200 mm.
  • Height: 1050 mm.
  • Ground Clearance Unladen: 280 mm.
  • Ground Clearance Laden: 130 mm.
  • Weight Unladen: 160 kg.
• Sidecar Specifications Electrical.

  • Orange Left Indicator/Red Tail Lamp; Brake/Orange Clearance.
  • Sidecar Specifications: Suspension/Brakes/Tyres.
  • Brake: Disc Brake.
  • Tyre: Kumo Tubeless Radial.
  • Maximum Load: 482 kg.
  • Size: P 165/75 R13 81S DOT H2AW YPM1.
  • Rim: Delta Australia Spoked Alloy Mag 13" x 5.5".
• This Rigid Wheelchair Accessible Sidecar Combination has been well maintained and serviced regularly.
• The FJ1200 was chosen to provide sufficient power to carry the load.
• A pleasure to ride.
